Two Stage Diesel Burner T 135 50-130 Kg/h

Two Stage Diesel Burner T 135 50-130 Kg/h

PRODUCT CODE	132.135
MIN \| MAX KG/H	50 kg/H \| 130 kg/H
WORKING	Two Staged
COMBUSTION	Diesel

Т 135 - ТМ 135 Two Stage burners with two magnet valves and servomotors provide of two-stage combustion and wide range of adjustment by changing the spray nozzle.

For delivery schedule and order, please contact our sales supervisor via our e-mail address info@gokceburner.com.

BURNER TYPE	T 135
ELECTRIC MOTOR	2.2 kW, 2800 d/d TRİFAZE
CONTROL UNIT	SIEMENS LMO 24
PHOTOCELL	SIEMENS QRB 4
TRANSFORMER	2 X 5000 V23 mA
HEATER	8000 Watt
SERVOMOTOR	SIEMENS SQN 31.121
SOLENOID VALVE	TORK 1/8” NK-NA DURAVİS 1/8” NK-NA
THERMOSTAT	ESM 4420 / THERMOWATT
PUMP	SUNTEC J6 NCK
